Booting process of broadband routers

Last week, we talk about how to find out the UART connections of an Orange router with a multimeter for getting root access to the device. We identified the pinout (GND, RX and TX pins) last week but today we are going to see how to connect the USB-to-UART converter and how to find out the baud rate easily for getting the booting process and accessing the root console. However, I have another broadband router this time to have fun, a Huawei EchoLife HG556a, which is an interesting device for my lab.

The best way to get the pinout is with an oscilloscope, if we don't have one, we can use a multimeter as we saw in the last post, and if we don't have this tools we can use another way for identifying useless pins and ground pin. However, this trick is not as much reliable than oscilloscope and multimeter, but helpful. The first thing we have to do is flashing a bright light from the backside of the PCB and look at it from directly above. This is what that looks like:

Identifying useless pins and ground pin in a Huawei router

We can see that some of the pins have lines meaning they are making contact with the PCB. For instance, it's easy to see that the forth pin doesn't have lines meaning it useless. What's more, the second one has four lines meaining is a power pin, either GND or Vcc. Finally, all other pins have a single line meaning they are TX, RX or Vcc. This trick is a little bit risky because we can break our device but if we don't have the right tools we can use this trick connecting each pin in turn to find out the pinout.

Once we know the pinout, we have to connect the USB-to-UART converter to the router. First, we should connect the GND pin between each other. Second, I would connect the TX pin of the router to the RX pin of the converter and, in this time, we should be able to see the booting process but not stop it or send or write something. At the end, I would connect the RX pin of the router to the TX pin of the converter and, in this time, we should be able to send information to the router like, for instance, username and password for getting root access.

Connecting converter to the router

We already know the pinout and how to connect the converter to the router but, maybe, we don't see any information yet through our miniterm/minicom application. This is because we have to configure the baud rate properly but, first, we should know what baud rate configuration we have to set. The best way to find out the baud rate configuration of an unknown serial device is with the Baudrate tool developed by Craig Heffner. Next, we can see that the tool allow us to change the baud rate configuration of our host system's serial por on the fly and with 115200 of baud rate we can read the output (letters) properly.

Baudrate tool

If we have got the baud rate configuration, we'll be able to see the booting process, and even stopping the autoboot process, and finally we'll see the console prompt to have root access.

Regards my friends, are you ready for doing whatever you want in your router?

10 de octubre de 2016

UART connections of an Orange router

This summer, I was building cross compilations Apps for broadband commercial routers. It is not an easy task for me but after hours and hours of working I got to install and run a “Hello world” application in my router. However, Apps and remote access services didn't remain after rebooting thus I wanted to go further because my goal is to have root access to do whatever. For this reason, this time, I wanted to have access by serial port connector to see the booting process. Let's try with an Orange broadband router.

First, surfing on Internet, I found that most routers have a serial port connector called UART and/or JTAG which are for programming and access to the console. It is like the RS232 connectors of computers but it isn't exactly the same, instead, it is a TTL serial, where a logic high ('1') is represented by Vcc, often 5V or 3.3V, and a logic low ('0') is 0V. Therefore, I disassembled the router to look for this connectors and I was looking the way to connect my laptop to the router, where I found two options, an USB-to-UART converter and the BusPirate electronic device, which is more professional and more expensive too, thus I bought the cheapest one, the converter.

USB-to-UART converter

Next step was to identify the pinout to know which pin is ground (GND), which pin is transmiting information (TX) and which pin can receive information (RX). This is important if we don't want to break/burn the mainboard (PCB) connecting pines in a wrong way. Let's begin with the easiest one, the ground pin.

The first pin that we have to identify is the ground (GND) pin. What tools we need? A multimeter. What more we need to know? We have to identify a ground place too in the mainboard which is easy because most mainboards have empty places ready for connecting capacitors, where we can see the minus symbol meaning ground. Next, connecting ground to each pin in turn with the multimeter we should look for 0V.

Identifying the ground pin

Once we know which pin is ground (GND), the next step is to identify the TX pin. This is a little more difficult because this pin is going to fluctuate between the Vcc value (3.3 volts) and ground (0 volts). Why? Because when it is transmiting bits of data, we'll see 3.3V, and when it is transmiting “spaces”, we'll see 0V. Therefore, we need a good multimeter because if it isn't so, the multimeter will do the average and it will be difficult to identify the TX pin. Another way to meter is with an oscilloscope, which is more expensive than a multimeter, or you can even make your own oscilloscope with your's computer sound card.

Identifying the TX pin

Finally, we have to identify the RX pin, which is the most difficult one. Why? Because there isn't a pattern. Therefore, the best way will be by process of elimination and connecting the serial converter to all possible receive pins individually, presssing a few keys in our terminal emulator and seeing what happens until we find out which one is the RX pin.

Arcadyan ARV7519RW22-A-LT pinout

This time, I have fun with an Arcadyan ARV7519RW22-A-LT router, we'll see in next posts how to connect the USB-to-UART converter for seeing the booting process and get the root access in other router as well.

Regards my friends and remember, test your thought and test whatever you are thinking.
